How to use slitting machine?

The slitting machine is a kind of mechanical device for cutting wide paper, glitter tape or film into several narrow materials. It is often used in paper-making machines, wire and cable-shining tapes, as well as printing and packaging machines.

What is the scope of application of slitting machine?

How can we set up the program before starting the slitting machine?

What are the structural advantages of slitting machines?

What is the scope of application of slitting machine?

1. Suitable substrates for the slitting machine: mica tape, paper, insulating materials and film slitting

2. Applicable industries of the slitting machine: related industries of various insulating materials, special electrical papers, and films

3. Applicable technology of the slitting machine: splitting, finished product inspection, finished product splitting, process cutting.

How can we set up the program before starting the slitting machine?

Power on

1. Switch on the electric disconnect switch (in front of the control cabinet), press the emergency reset and ready-to-use buttons, switch on the machine (at the main console) with the key and check that the voltage (380V) and current are correct and stable.

2. Turn on the main switch of the hydraulic system of the sliding machine (set at the main hydraulic drive frame) and check that the oil and manometer display of the main hydraulic drive system is correct and stable.

3. Open the pneumatic shut-off valve (set at the air inlet tube under the pneumatic control cabinet) and check that the air pressure is correct (not under 6.0 bar) and stable.

Configure Control

1. Set the editing menu according to the type, thickness, length and width of the sheet as specified in the cutting plan.

2. Remove the corresponding BOPP film file from the PDF.

3. Set the winding length and width of the foil according to the corresponding specification of the slitting machine.

4. Select the appropriate winding station, set up the printing roller frame and the printing roller and install the paper core of the corresponding specifications.

What are the structural advantages of slitting machines?

The paper sleeve slitting machine is equipped with a main wave for processing the paper sleeve in the middle. The front end of the main shaft is fixed to the base with a bearing set and a belt disc is installed in the middle of the bearing set; a compression cylinder is installed near the base and is carried by the cylinder. At the top of the bar is a set of support rod bearings installed to support the main wave.

The main knife wave is installed at the top of the paper tube slitting machine and a number of knives are arranged on it and are arranged in a specific column; the main knife-wave support frame is also set on top of the paper-rotary slitting machine, in the support frame In the middle is a support cylinder installed.

The constructive advantages of the paper rotary slitting machine close the technical gap of the automatic tube slitting machine.

ZHEJIANG GREENPRINT MACHINERY CO.,LTD has focused on the development and production of slitting machines for several years. And it commits to provide perfect service for every customer from all over the world.
